Overload Protection Reliable LED Driver Power Supply 120W 12VDC 10A IP20 EPA3052 HG-120-12 manufacturer from China Shenzhen Dongdahua Technology Co.

Overload Protection Reliable LED Driver Power Supply 120W 12VDC 10A IP20 EPA3052

Place of Origin:

Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HG-120-12

Overload Protection Reliable LED Driver Power Supply 120W 12VDC 10A IP20 EPA3052
<p

Overload Protection Reliable LED Driver Power Supply 120W 12VDC 10A IP20 EPA3052

Specifications:

Product Electric Parameters
Input specification	Input voltage	AC176V---264V
	Input frequency	47-63Hz
	Input surge	20A@120VAC 40A@230VAC
Output specification	Output voltage can be adjusted	±10%
	Start-up time	1S(input230V, Io=100%)
	keep time	20mS (input230V, Io=100%)
	Voltage regulation	(Full load) 0.5%
Protection function	Overload protection	105% - 150% rated power, automatic recovery
Protection function	Over-voltage protection	105% - 150% of the rated voltage
Insulation intensity	Input---output	1500VAC/1min
	Input---ground	1500VAC/1min
	Input---ground	500VAC/1min
Safety standards	According with GB4943, EN60950-1 ; EPA3050B:1996; EN1122:2001 ; EPA3052:1996; EPA3060A; EPA7196; EPA3540C;EPA8270C standards.
E M C standards	According with EN55022 class A EN61347-2-13:2008 standards
Environmental	working temperature	- 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost)
	Storage temperature	- 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost)
	height above sea level	2000M
Structure	Size (mm)	162(L)97(W)42(H)
Cooling method	Cooling method	Natural cooling air convection
